With smart design and elegant appearance, the MUST LiFePO4 battery is an ideal replacement for traditional lead-acid batteries, offering a drop-in solution for lead-acid battery replacement. Our battery can be used individually or assembled in series to create a larger system.
Lithium iron phosphate can be used in most applications that use lead acid, GEL, or AGM-type batteries.
Suitable applications include
• Caravan
• Marine
• Golf Car
•Buggies
• Solar Storage
• Remote Monitoring
• Switching applications and more
High cycle life
6000 Cycles (25°C, 80% DOD) for effectively lower total of ownership cost
Longer service life
Low-maintenance batteries with stable chemistry.
Built-in circuit protection
Battery Management System (BMS) is incorporated against abuse.
Better storage
up to 6 months thanks to its extremely low self-discharge (LSD) rate and no risk of sulfation.
Quickly recharge
Save time and increase productivity with less downtime thanks to superior charge/discharge efficiency.
Extreme heat tolerance
Suitable for use in a wider range of applications where ambient temperature is unusually high: up to +60°C.
Lightweight
Lithium batteries provide more Wh/kg while also being up to 1/3 the weight of their SLA equivalents.
•Do NOT short circuit, reverse polarity, crush, or disassemble.
• Do NOT heat or incinerate.
•Do NOT immerse in any liquid.
• Store at 30~50% SOC. Recharging every 3 months is recommended. The storage area should be clean, cool, dry, and ventilated.
| MODEL | LP15-24200 | |
|---|---|---|
| Nominal voltage | 25.6V | |
| Nominal Capacity | 200 Ah | |
| Nominal energy | 5120Wh | |
| Life Cycles | 6000 Cycles (25℃, 80% DOD) | |
| Recommended Charge Voltage | 29.2V | |
| Recommended Charge Current | 20.0A | |
| End of discharge voltage | 20.0 V | |
| Standard method | Charge | 40.0A |
| Discharge | 100.0A | |
| Maximum continuous current | Charge | 100.0A/200.0A |
| Discharge | 100.0A/200.0A | |
| BMS Cut-Off Voltage | Charge | <31.2 V (3.9V/Cell) |
| Discharge | >16.0 V (2s) (2.0V/Cell) | |
| Temperature | Charge | -4 ~ 113 ℉ (0 ~ 45℃) |
| Discharge | -4 ~ 131 ℉ (-20 ~ 55 ℃ ) | |
| Storage Temperature | 23~95 ℉ (-5~35℃ ) | |
| Shipment voltage | ≥25.6V | |
| Case Material | ABS+PC | |
| Dimension (L x W x H) | 522 x 240 x 218 mm (20.6 x 9.5 x 8.6 in.) | |
| Approx. Weight | 99.2 lbs (45 kg) | |
| Charge retention and capacity recovery capability | Standard charge the battery, and then put aside at room temperature for 28 days or 55 ℃ for 7 days. Charge retention rate ≥ 90%, Recovery rate of charge ≥ 90% | |
